The TechGrow T-1 is a digitally controlled machine which measures and regulates the CO2 values in a room. It is equipped with a modern digital display on which you can easily read the CO2 values and set the desired value, ranging between 300 ppm and 2000 ppm.
The T-1 has a solid and robust splash proof casing and can be entirely operated by a single Push & Turn button.
The T-1 is also equipped with a min/max meter to display the minimum and the maximum CO2 values in a room.
The T-1 has a separate CO2 sensor connected via UTP cable, allowing you to perform measurements at various points in the room, as well as a light sensor which registers the difference between night and day.
Special features:
-
Can be used in small to very large rooms, Plug&Play.
-
Adjustable between 300 – 2000 ppm.
-
Extremely accurate external CO2 sensor, produced by SenseAir® Sweden, the absolute market standard in CO2 measurement.
-
The CO2 sensor has a built-in light sensor to automatically switch between day and night settings.
-
The sensor performs a new measurement every second.
-
Turns the CO2 source (CO2 generator, CO2 cylinder) on/off using a 220V relay.
-
Automatically detects whether the CO2 sensor has been connected correctly (i.e. broken cable, bad connection).
-
Connecting the sensor is done with a standard network cable (UTP).
-
Modern blue-white display with automatic background lighting.
-
Automatic 110V – 230V detection.
-
Memory for power outages for: setpoint, hysteresis CO2 level.
-
LED indicator when CO2 is being dosed.
-
Built-in calibration function to calibrate the CO2 sensor against outdoor air.
T1 CO2 controlelr Technical specifications:
Power supply: 110V/230V (automatic)
Consumption: 3 Watt (with sensor, without CO2 source)
Range CO2 set: 300 to 2000 ppm
Range CO2 +/-: 10 to 200 ppm (advice 50 ppm)
Measurement time: 1 measurement per second
